FT - LD - 48V12Ah - LFP Lifepo4 Rechargeable Battery For E - Bike / Electric Bicycle

Product Categories

FORZATEC CO., LIMITED

Contact Now

Name: FT LD 48V12Ah LFP Lifepo4 Rechargeable Battery For E Bike Electric Bicycle
Brand: FORZATEC
Price: 1 USD

Brand Name : FORZATEC

Model Number : FT-LD-48V12Ah-LFP

Certification : CE&ROHS

Place of Origin : CHINA

MOQ : 50

Payment Terms : L/C, T/T

Supply Ability : 1,000 PER MONTH

Delivery Time : 15 DAYS

Packaging Details : CARTON AND PALLETS

Nominal Voltage : 48V

Nominal Capacity : 12Ah

Dimension(L*W*H*TH) : 280*158*85 mm

Discharge : - 10 ~ 55 ℃

Storage : - 10 - 35 ℃

Discharge current : 20A

Contact Now

FT-LD-48V12Ah-LFP E-bike & E-scooter Lithium Battery for Electric Vehicle

Details		Min.	Typ.	Max		Error	Unit
Battery Gas		3.2V
Battery Link		15S
Loop capability
Input Charging Voltage			54.6		±1%		V
Input Charging Current			≤10				A
Output Discharging Voltage			37.5		±1%		V
Continuous Output Discharging Current			≤20				A
Protection Parameters (for Individual Cell)
Over-Charge Voltage Protection (OVP)			3.75		±0.025		V
Over-discharge protection delay time			1.0		±0.5		s
Over-Charge Voltage Protection Release (OVPR)			3.60		±0.05		V
Over-Discharge Voltage Protection (UVP)			2.1		±0.1		V
Over-discharge protection delay time			0.2		±0.05		s
Over-Discharge Voltage Protection Release (UVPR)			2.3		±0.1		V
Over-DischargeProtection Release		Release load
Over-Current Discharge Protection (OCDP)			75		±5		A
Over-Current Protection Delay Time (OCPDT)			0.1		±0.05		s
Over-Current Discharge Protection Release		Release load
Short circuit current protection		Enable
Short circuit current protection delay time			200				uS
Short circuit protection Release		Release load
Idle mode		≤60					uA
Main loop electrify resistance MOS-R_DS		≤40					mΩ
PCBA Size	70(±1)×52(±1)×<10						mm

Working Voltage	rated Voltage	48.0V
	Voltage range	37.5V--54.6V
Core combination mode	IFR32700-6.0AH/15S2P
Nominal Capacity (Ah)	12AH
Battery Energy	576Wh
Working Temperature:	: Charging:0℃ ~ 55℃ Discharge :-20℃ ~ 60℃
Continuous charging current (A)	≤20A(0.2C)
Continuous discharge current (A)	≤20A(0.2C)
Storage Temperature/Humidity	-20 ~ 60℃ Humidity RH≤95%
Weight (kg)	about 6kg
Output	Charge and Discharge Port: Pingzi Socket
Cycle life	>1500 (@0.2CA 70%DOD)
Protection Function	Overcharge Protection; Overdischarge Protection; Overcurrent Protection; Short Circuit Protection
Internal resistance (internal resistance at discharge end)	≤100mΩ
Out-of-factory voltage	≥45V
Profile Size(MAX)	LWH=(280±1)X(158±1)X(85±1)mm
Shell Material	Iron Box Baking Paint
